Brand Name : YuanTe
Model Number : SKY2000-C8H10
Certification : CNEX,ISO9001,CE
Place of Origin : China
MOQ : 1 piece
Price : Negotiable
Payment Terms : Western Union, T/T
Supply Ability : 1000 pieces/week
Delivery Time : 3-5 working days
Packaging Details : Aluminum Suitcase
Detected Gas : Xylene C8H10
Measure Range : 0-1PPM,0-10PPM,0-50PPM,0-100PPM,0-200ppm,0-1000ppm、0-6000ppm、0-10000ppm
Sampling Method : Pumping Suction
Alarm Type : Sound, Light, Vibration
Size : 205*75*32mm
Weight : 300g
Charging Method : Power Adapter, USB Cable
Packing : Aluminum Suitcase
Portable PID Theory High Precision Xylene C8H10 VOC Gas Detector With ISO Certificate
YuanTe's Xylene C8H10 gas analyzer can use in paint, printing, packaging, cars, enameled wire, pharmaceutical factories and other industrial emission detection areas.
Specifications
Gas Detected | C6H6 Benzene | ||
Detection principle | PID | ||
Sampling Method | Pumping suction, flow rate can up to 1L/min, ten grades of pumping suction for selection. | ||
Measure Range | 0-1PPM,0-10PPM,0-50PPM,0-100PPM,0-200ppm,0-1000ppm,0-6000ppm,0-10000ppm | ||
Resolution | 0.001ppm,0.01ppm,0.1ppm,1ppm | ||
Precision | ≤± 2% F.S. | ||
Signal Output | High-speed data transmission by USB, available for data downloading and | ||
Response Time | ≤10S | Recovery Time | ≤10S |
Repeatability | ≤±1% | Linearity error | ≤±1% |
Zero shift | ≤±1%(F.S/year) | Display | LCD dot matrix display |
Operating language | Chinese/English | Gas unit | Units are switchable |
Temperature | -20℃~50℃ | Humidity | 0-95%RH |
Explosion-Proof | ExiaⅡCT4 | Degree of protection | IP66 |
Alarm mode | Sound, light, vibration | Operating time | 100h(pump off) |
Dimensions | 205*75*32mm | Weight | 300g |
Functions:
1. LCD dot matrix display, the gas type, unit, concentration, local time, temperature and max measure value (optional) can be showed on the screen.
2. Support Chinese and English operation, easy to shift.
3. The gas concentration unit PPM and mg/m3 can be shifted quickly.
4. Explosion-proof certification, explosion-proof grade: ExiaⅡCT4.
5. Monitor the Xylene C8H10 concentration in environment and enclosed space and alarm.
6. With Self-calibration and zero calibration functions, makes the detection more accurate and reliable.
7. One press to restore factory setting, free from the bother of mis-operation.
8. With temperature and pressure compensation, to realize gas concentration compensation under conditions of different temperatures or pressures.
9. Two stages alarm with sound and light, alarm point is settable.
10. Rechargeable lithium polymer battery of large capacity.
Why choose YuanTe's detector?
1.For all our customers, we guarantee one year warranty, and life-long maintenance.
2.All inquiries will be replied in 24 hours.
3.We will provide technical support, our engineers will help to solve the problems you met.
4.We can provide OEM service.
5.We are manufacturer with own factory, welcome to visit our factory.
6.All products will be well checked and well packed before shipment, and qualification certificatewill be provided.
![]() |
