Fixed NDIR Infrared Single Gas Detector Carbon Dioxide CO2 Detector With Imported CITY Sensor
Funtions:
1. Monitor the Carbon Dioxide CO2 gas in environment or pipeline.
2. With self-calibration and zero calibration function, makes the detection more accurate and reliable.
3. With temperature compensation, this is able to realize gas concentration compensation under conditions of different temperatures.
4. Infrared ray controller can remote control alarm point settings, zero calibration, and address modification. (optional)
5. Can output one or two on-off signals, can drive ventilator or solenoid valve and other external devices. (optional)
6. Working Voltage:24V DC
7. Case: die-cast aluminum
Specification
| Gas detected | Carbon Dioxide, CO2 |
| Detection principle | IR |
| Install method | Wall-mounted, piping type, flow-type (according to the detected environment) |
| Measure range | 0-1000ppm, 0-2000ppm, 0-10000ppm, 0-6000ppm, 0-20%VOL, 0-50%VOL, 0-100%VOL |
| Resolution | 0.1ppm, 1ppm, 0.001%VOL, 0.1%VOL |
| Precision | ≤± 1% FS or ± 2-3% FS |
| Signal output | 4-20mA, 0-5V, RS485, relay(optional) |
| Response time | ≤10S | Recovery time | ≤10S |
| Repeatability | ≤±1% | Linearity error | ≤±1% |
| Zero shift | ≤±1%(FS/year) | Display | High-light nixie tube display |
| Connection mode | G1/2 external thread explosion-proof flexible pipe | Unit | ppm |
| Temperature | -20 to 50°C | Humidity | 0-95%RH |
| Explosion-proof | Ex dⅡCT6 | Degree of protection | IP65 |
| Alarm | Sound, light | Operating time | 24H |
| Dimensions | 180*150*90mm | Weight | ≤2kg |
Characteristics:
1. Standard equipped with three-wire system 4-20mA analog output; relay output; RS485 output.
2. Unique infrared ray control function, which can non-contacted control the device.
3. Being compatible with all kinds of controlled alarms, PLC, DCS and other control system, can be remote monitored.
4. Explosion-proof design, fast, reliable and stable.
5. Explosion-proof grade: Ex dⅡCT6
6. With self-calibration function, and three standard keys will be used to realize on-site maintenance.
7. Detachable probe/gas cell: It is very easy to calibrate and replace sensor
Application
- Petrochemical industry, industrial manufacture, smelting, electricity, coal mining, tunneling, environment monitoring, waste water treatment.
- Bio-pharmaceutical plant, green household, livestock breeding, green house cultivating, warehouse logistics, brewing and fermentation, agricultural production.
- Fire control, fuel gas, building, municipal enterprise, school lab, research centre.
